The mesh belt drying machine is using hot air as drying medium, material is conveyed by multi-layers stainless steel mesh belt. The hot air through the mesh belt from the bottom layer to the top layer, finally, the moisture goes out the top of the dryer and the dried goes out the discharge conveyor. The heat source have electricity, gas, diesel, wood, biomass, boiler. You can choose the one that is most convenient and economical for you.
Characteristics
1. The mesh belt drying machine uses the hot air produced by the oven heat as the drying medium. Through the hot air distribution unit, the hot air is transported to the mesh belt.
2. The volume of hot air, mesh belt running speed, temperature and humidity can be adjusted through the electric control system, to ensure continuous and automatic operation.
3. The mesh belt drying machine not only according to the heat to dry, but also according to the strong air, the air volume can reach 40000 cube meters per hour.
Parameter
| Model | GD-8 | GD-9 | GD-10 | GD-12 |
| Layer | 4 layers, 5 layers, 6 layers | |||
| Material thickness | 10-70mm | |||
| Drying temperature | 40~120°C | |||
| Humidity reduce | 75% to 8% (Customized) | |||
| Drying time | 0.5-5 hours | |||
| Power of main engine | 1.5kw | 1.5kw | 2.2kw | 3kw |
| Hot air draft fan | 15kw | 15kw | 22kw | 22kw |
| Conveyor discharge | B500(0.12kw) | B500(0.12kw) | B500(0.12kw) | B500(0.12kw) |
| Note:The above parameters are for reference, we customize the machine according to customers&rsquo requirements and provide the best solutions. | ||||
Q1 Could you supply all the parameters about the machines?
A: Of couse. We are delighted to supply all the informtion that you want to know.
Q2 How about the after sale service?
A: We will send our engineers to your factory for installation and training.
Q3 Can I specify the heat source?
A: Yes, the general machine can use electricity or natural gas as a heat source.Mesh belt dryers can use electricity and natural gas as well as steam or coal.A wide range of heat sources, which is available for customers to choose independently.
Q4 What is your terms of payment ?
A: 30% T/T in advance , 70% balance before shippment after inspection.
Q5 What kind of drying machine is suitable for me?
A:We offer three types of food dryer machine: multi-layer belt drying machine, heat pump drying machine and microwave food drying machine. Generally speaking, multi-layer belt drying machine is more suitable for large-scale food drying, heat pump drying machine tends to be easier to operate and frequently used in the small and medium drying process, and The microwave dryer has higher drying efficiency and sterilization function. Based on your production situation, you can choose the suitable one.
1. 24-hour communication service
2. Fast logistics will provide you a smooth delivery service
3. One-year warranty and lifetime technical support
4. New design or product recommendation
5. Attend international exhibitions and have face-to-face negotiations with customers
6. If you want to come to China, we will send a formal invitation
7. The front desk service will help you book a good hotel
