Product Name | Pressure measuring film |
| Type | LW LLW LLLW 4LW | |
| Thickness | 90um |
|
| Material | 100% Polyethylene | |
| Size | 270mm*5m/6m/10m | |
| Color | white | |
| Application | Cof Bonding Head Calibrate | |
| Temperature | 20-35 Degree |
|
Product Code
|
Width
|
Length
|
Pressure range
(MPa)
|
Type
|
|
Ultra-Super Low Pressure
(3LW)
|
270mm
|
5m
|
0.2~0.6 |
Two-sheet type
|
|
Super Low Pressure
(2LW)
|
270mm
|
6m
|
0.5~2.5
|
Two-sheet type
|
|
Low Pressure
(1LW)
|
270mm
|
10m
|
2.5~10
|
Two-sheet type
|
- Precisely measure pressure, pressure distribution, and pressure balance.
- Contact pressure shown with differing concentrations of color can even be converted into
- numbers by calculation.
- Quick measurement, gives a clear and visual picture.
|
Item
|
L-Sheet
|
K-Sheet
|
|
Color
|
Cream White (Light Pink)
|
White
|
|
Thickness
|
(95±10) &mum
|
(90±15) &mum
|
|
Precision
|
10% (measured by densitometer at 23℃, 65%RH)
|
|
|
Operational
Environment
|
Recommended temperature: (20-35)℃
Recommended humidity: (35-80)%RH
|
|
1. Do you have any certificates?
Our products passed inspection of SGS,ISO.Quality is priority! QC department especially responsible for quality checking in each process.
2.Are you a manufacturer?
We have factory,so we can control the good quality and can give you the best price.
3.How can I get some samples?
We are very happy to send you free samples to check our quality, but you need to provide your express account. We will credit this fee for you in future order.
4.How should I afford the sample freight fee?
1) It will be convenient if you any courier account.
2) If you don&rsquot have any account, you can sent the freight fee by Paypal or alibaba we will send by FEDEX or DHL after receive the freight fee.
5.Can you print my logo on the packing bag?
Yes, we can print your logo on bag or carton.
6.Why choose you?
1)17 years export experience.
2) Good service make you free from worry.
3) We are trying to bring maximum profit to our customers and we only share small.
|
