IFMA0035 Bộ chuyển đổi F sang A cách ly 9-32VDC Nguồn điện DIN Rail Mount 4-20mA Mô-đun đầu ra sẵn sàng giao hàng
IFMA0035 Bộ chuyển đổi F sang A cách ly 9-32VDC Nguồn điện DIN Rail Mount 4-20mA Mô-đun đầu ra sẵn sàng giao hàng
Yêu thích
IFMA0035 Bộ chuyển đổi F sang A cách ly 9-32VDC Nguồn điện DIN Rail Mount 4-20mA Mô-đun đầu ra sẵn sàng giao hàng
5
416
Đã bán
23.165.791đ
IFMA0035 Bộ chuyển đổi F sang A cách ly 9-32VDC Nguồn điện DIN Rail Mount 4-20mA Mô-đun đầu ra sẵn sàng giao hàng
Số lượng
Đơn vị
1 Đơn vị
Chọn loại hàng (ví dụ:màu sắc ,kích thước)
Thông số sản phẩm
Mô tả sản phẩm
Product Description
The Model IFMA accepts a frequency input, and outputs an analog voltage or current in proportion to the input frequency, with 0.1%
accuracy. The full scale input frequency can be set to any value from 1 Hz to 25 KHz, either with a frequency source, or digitally
with the on-board rotary switch and push-button. The IFMA utilizes a seven position DIP switch, a rotary switch, a push-button and
two indication LEDs to accomplish input circuit configuration, operational parameter set-up, and Input/Output indication. The
input circuitry is DIP switch selectable for a variety of sources. The indication LEDs are used during normal operation to display
the input and output status of the IFMA. These LEDs are also used to provide visual feedback to the user of the existing parameter
settings during parameter set-up. The IFMA operates in one of four output modes. The programmable minimum and maximum response
times provide optimal response at any input frequency. The unit is equipped with a universal mounting foot for attachment to
standard DIN style mounting rails, including top hat profile rail according to EN 50 022 - 35 x7.5 and 35 x 15, and G profile rail
according to EN 50 035 - G 32. Features:
●Simple On-Line Range Setting (Using Actual Input Signal or Signal Generator)
●User Settable Full Scale Frequency from 1 Hz to 25 kHz
●Four Output Operating Ranges (0 to 5 V, 0 to 10 V, 0 to 20 mA, and 4 to 20 mA)
●Programmable Input Circuit Accepts Outputs from a Variety of Sensors
●Low Frequency Cut-Out and Overrange Indication
●3-Way Electrical Isolation (Power/Input/Output)
accuracy. The full scale input frequency can be set to any value from 1 Hz to 25 KHz, either with a frequency source, or digitally
with the on-board rotary switch and push-button. The IFMA utilizes a seven position DIP switch, a rotary switch, a push-button and
two indication LEDs to accomplish input circuit configuration, operational parameter set-up, and Input/Output indication. The
input circuitry is DIP switch selectable for a variety of sources. The indication LEDs are used during normal operation to display
the input and output status of the IFMA. These LEDs are also used to provide visual feedback to the user of the existing parameter
settings during parameter set-up. The IFMA operates in one of four output modes. The programmable minimum and maximum response
times provide optimal response at any input frequency. The unit is equipped with a universal mounting foot for attachment to
standard DIN style mounting rails, including top hat profile rail according to EN 50 022 - 35 x7.5 and 35 x 15, and G profile rail
according to EN 50 035 - G 32. Features:
●Simple On-Line Range Setting (Using Actual Input Signal or Signal Generator)
●User Settable Full Scale Frequency from 1 Hz to 25 kHz
●Four Output Operating Ranges (0 to 5 V, 0 to 10 V, 0 to 20 mA, and 4 to 20 mA)
●Programmable Input Circuit Accepts Outputs from a Variety of Sensors
●Low Frequency Cut-Out and Overrange Indication
●3-Way Electrical Isolation (Power/Input/Output)
Specification
Product Attribute | Attribute Value |
Manufacturer | Red Lion Controls |
Current Rating | 600 A |
Input Type | Frequency |
Manufacturer Part Number | IFMA0035 |
Maximum Operating Temperature | 50 C |
Minimum Operating Temperature | 0 C |
Module Type | Converter |
Mounting Type | DIN Rail Mount |
Number of Channels | 1 |
Numeric ID | 4079255 |
Output Type | Current, Voltage |
Primary Type | Signal Converter |
Range Input | 0 Hz to 25 kHz |
Series | IFMA Series |
Temperature Operating Range | 0 to +50 C C |
Termination | screw |
Type | Pulse Rate (Frequency) - Analog Converter |
