Máy Nghiền Búa Gỗ Viên Mùn Cưa Ngô Nhỏ Cho Dăm Gỗ
999
Đã bán
88.645.922đ
73.789.064đ ~ 88.645.922đ
88.645.922đ
73.789.064đ ~ 88.645.922đ
Chọn loại hàng (ví dụ:màu sắc ,kích thước)
Thông số sản phẩm
0%
73.789.064đ
bkH2hE66H0
Mô tả sản phẩm
Nơi xuất xứ: Henan, ChinaNhãn hiệu: bedo
Điều kiện: MớiVideo Gọi Đi-Kiểm Tra: Cung Cấp
Máy Móc Báo Cáo Thử Nghiệm: Cung CấpTiếp Thị Loại: Sản phẩm mới 2024
Bảo Hành Của Core Thành Phần: 1 NămCore Thành Phần: Động Cơ, Chịu Lực, Hộp Số
Điện áp: 220V/380V/tùy chỉnhCông suất (HP): 22Kw
Kích thước (L * W * H): 2400*1500*3500m mBảo hành: 1 Năm
Key Điểm Bán Hàng: Năng Suất caoÁp dụng Các Ngành Công Nghiệp: Nhà Máy sản xuất, Thực phẩm và Đồ Uống Nhà Máy, Các trang trại, Nhà hàng, Nhà Sử Dụng, Bán lẻ, Năng lượng & Khai Thác Mỏ, Thực phẩm và Đồ Uống Cửa Hàng
Phòng Trưng Bày Trí: Hoa Kỳ, Ý, Đức, Việt Nam, Brasil, Peru, Ả Rập Saudi, Indonesia, Pakistan, Ấn Độ, Mexico, Nga, Thái Lan, Maroc, Kenya, Argentina, Nam Hàn Quốc, Chile, Algérie, Sri Lanka, Romania, Bangladesh, Nam Phi, NigeriaTrọng lượng (KG): 800
Tên: Ngô mùn cưa gỗ PELLET nhỏ Hammer Mill cho gỗ chipLoại: BD-CP500
Sử dụng: Mài nguyên liệuNguyên liệu thô: Ngũ Cốc lúa mì ngô hạt ngô
Lợi thế: Công suất cao hiệu quả caoCách điều khiển: Động cơ điện động cơ diesel
Màu sắc: Yêu cầu của khách hàngTính năng: Hoàn toàn tự động hiệu quả cao
Sản phẩm cuối cùng: 3-8cmMáy liên quan: Máy trộn, Thức ăn viên máy
Corn Sawdust Wood Pellet Small Hammer Mill for Wood Chips
Product Description
Hammer crusher is a tangent-feeding hammer crusher, which can crush all kinds of dry feed, such as corn, sorghum, husk, rice straw, wheat straw, yam vine, corn stalk, peanut vine, bean stalk, etc. This series of crusher has simple structure, high production efficiency, simple operation, reliable use and easy maintenance Suitable for farms, livestock farms, counties, township processing plants. In addition, the machine can also crush traditional Chinese medicine materials, animal bones, wood, waste paper, cow dung, pharmaceutical raw materials, chemical raw materials.
Specification
Compared with other similar products, the performance of wood crushing machine has been greatly improved.
1.The whole equipment is only driven by a motor, simple structure, compact layout, cheap price, stable work, less energy consumption, high output, wood chip machine finished product quality, low processing cost. In addition to wood, it can also be used for bamboo, thatch, corn stalk, sorghum stalk and other fibrous straw like chips.
2.Wood pulverizer can also be called wood pulverizer, large wood pulverizer, small wood pulverizer, wood sawdust machine, wood pulverizer can be processed, pine, miscellaneous wood, young wood, fir, bamboo, because the machine compact structure, small footprint, cutting quality, low power consumption, and suitable for flow operations, It is widely used in the preparation section of medium and small particleboard and fiberboard production enterprises, and can also be used in the production of commercial wood chips for individual households.
3.Wood crusher is a hammer crusher, it is mainly the use of blade chips and airflow impact principle to crush the material to be crushed. This equipment is mainly composed of crushing, grading, wind conveying, unloading and dust removal five major parts,cancel the traditional screening process, the use of wind once into powder.
1.The whole equipment is only driven by a motor, simple structure, compact layout, cheap price, stable work, less energy consumption, high output, wood chip machine finished product quality, low processing cost. In addition to wood, it can also be used for bamboo, thatch, corn stalk, sorghum stalk and other fibrous straw like chips.
2.Wood pulverizer can also be called wood pulverizer, large wood pulverizer, small wood pulverizer, wood sawdust machine, wood pulverizer can be processed, pine, miscellaneous wood, young wood, fir, bamboo, because the machine compact structure, small footprint, cutting quality, low power consumption, and suitable for flow operations, It is widely used in the preparation section of medium and small particleboard and fiberboard production enterprises, and can also be used in the production of commercial wood chips for individual households.
3.Wood crusher is a hammer crusher, it is mainly the use of blade chips and airflow impact principle to crush the material to be crushed. This equipment is mainly composed of crushing, grading, wind conveying, unloading and dust removal five major parts,cancel the traditional screening process, the use of wind once into powder.
Technical Data
After crushing the size can be adjusted according to customer requirements, is currently a best-selling domestic farm necessary equipment. A machine that uses high-speed spinning hammers to crush feed. When the material is evenly into the crushing chamber, under the action of rotating sheet continuous high-speed strike and crushing chamber rub collision, quickly broken into fine powder, through the screen through the discharge port discharged from the machine. It has the characteristics of simple structure, strong commonality, high productivity and safe use.
Model | Power (kw) | Capacity (kg/h) | The number of hammer pieces(pcs) | The size of hammer pieces(mm) | Packing Size (mm) | Weight (kg) |
BD-CP500 | 22 | 700-1000 | 30 | 180*60*8 | 2100*1260*980 | 540 |
BD-CP600 | 30 | 1200-1500 | 40 | 180*60*8 | 2000*1400*1200 | 650 |
BD-CP800 | 45 | 2000-2500 | 60 | 180*60*8 | 2200*1500*1250 | 820 |
BD-CP1000 | 75 | 3000-3500 | 70 | 180*60*8 | 2200*1650*1300 | 1300 |
BD-CP1300 | 45+45 | 4000-5000 | 90 | 230*60*8 | 2300*1700*1400 | 2400 |
BD-CP1500 | 55+55 | 5000-6000 | 100 | 230*60*8 | 2300*1750*1420 | 2800 |
Details Images
Hammer crusher is composed of feeding hopper,upper and lower body, rotor, screen, feeding tube and other parts. Users can be equipped with storage bags or silos according to their own needs. After the material enters the crushing chamber from the hopper, it is broken by the high-speed rotating hammer.
Under the air flow, the broken material along the outer edge of the rotor, continuous and hammer, tooth plate, screen, collision,rub and be quickly crushed. The pulverized powder particles are quickly transported to the storage bag or bin through the sieve by centrifugal pressure of the rotor and suction force of the fan.
Under the air flow, the broken material along the outer edge of the rotor, continuous and hammer, tooth plate, screen, collision,rub and be quickly crushed. The pulverized powder particles are quickly transported to the storage bag or bin through the sieve by centrifugal pressure of the rotor and suction force of the fan.
Raw Materials and Final Production
Usage and scope of application:
1.Straw dry feed:can crush chaff, belly valley, potato rattan, peanut rattan, straw, corn xuan, bean straw, etc.
2.Grain flour:rice, sweet potato, beans, wheat, jade, potatoes, etc., can be the supporting machinery of flour mill.
3.Oil processing:powder tea seeds, rapeseed, peanut, tong kernel, cotton seeds are the supporting machinery of oil press.
1.Straw dry feed:can crush chaff, belly valley, potato rattan, peanut rattan, straw, corn xuan, bean straw, etc.
2.Grain flour:rice, sweet potato, beans, wheat, jade, potatoes, etc., can be the supporting machinery of flour mill.
3.Oil processing:powder tea seeds, rapeseed, peanut, tong kernel, cotton seeds are the supporting machinery of oil press.
Packing & Delivery
Packaging
For one set charring kiln, it is packed by waterproof cloth, then packed in the container.
For more than two sets charring kiln, it is nude packing, packed in the full container.
Payment term
1. Payment: T/T, Western Union 50% TT payment in advance, 50% TT pay the balance before delivery.
2. Warranty: 12 months for the main machine, 4-6 months for the parts.
3. Delivery time: Within 7-10 days for single machine after getting the down payment 25-35 days for the whole production line after getting the down payment.
For one set charring kiln, it is packed by waterproof cloth, then packed in the container.
For more than two sets charring kiln, it is nude packing, packed in the full container.
Payment term
1. Payment: T/T, Western Union 50% TT payment in advance, 50% TT pay the balance before delivery.
2. Warranty: 12 months for the main machine, 4-6 months for the parts.
3. Delivery time: Within 7-10 days for single machine after getting the down payment 25-35 days for the whole production line after getting the down payment.
