Nguồn cấp điện QUINT POWER Series GEN 3, model 100% TH, 24VDC, 10A, 240W, lắp đặt trên thanh ray DIN
Mô tả sản phẩm
Specification
Product Specifications | |
Product Attribute | Attribute Value |
Alternate Mfr Part Number | QUINT-PS/1AC/24DC/10/CO |
Manufacturer | PHOENIX CONTACT |
Configuration | Enclosed |
Family Name | GEN 3 |
Manufacturer Part Number | 2320911 |
Mounting Type | DIN Rail Mount |
Number of Outputs | 1 |
Numeric ID | 2510413 |
Operation | switching |
Output Current | 10 A |
Output Power | 240 W |
Output Voltage | 24 VDC |
Primary Type | AC-DC |
Type | GEN 3 |
UPC Code | 4.04636E+12 |
Warranty | Limited Lifetime |
Phoenix Contact QUINT POWER Series - Single-Phase Primary-Switched Power Supply Unit:
For extreme operating conditions, use the ideally matched combination of PLUGTRAB SEC surge protection device and the powerful
QUINT POWER power supply of the fourth generation. However, should your fourth-generation QUINT POWER become damaged in the first
five years following purchase despite the use of this combination, you will receive a free replacement .
The Power Boost power reserve easily starts loads with high inrush currents and ensures that fuses are reliably tripped.
Preventive function monitoring diagnoses impermissible operating states and minimizes downtimes in your system. Remote monitoring
is provided by an active transistor switching output and a floating relay contact. All devices are idling-proof and
short-circuit-proof, and are available with a regulated and adjustable output voltage of 12, 24, and 48 V DC with output currents
of 2.5, 5, 10, 20, 30, and 40 A. Power supply units for use in Ex zone 2, uninterruptible solutions, AS-i power supply units, and
a QUINT diode complete this comprehensive product range.
Features:
● Startup of heavy loads, thanks to dynamic boost
● Preventive function monitoring reports critical operating states before errors occur
● High efficiency and long service life with low power dissipation and low heating
● Space savings in the control cabinet, thanks to a narrow, slim-line design
● Free selection between Push-in and screw connection
● QUINT POWER is the powerful 60 - 960 W DC power supply unit for universal use
With its wide-range input, single and three-phase versions, and international approval package, this solution is unrivalled
● QUINT POWER provides reliable power supply: generously dimensioned capacitors ensure mains buffering of over 20 ms at full load
● Full output power is provided by all three-phase devices, even in the event of a permanent phase failure
● Quick, tool-free installation with Push-in connection technology
● Increased service life and availability of the system, thanks to optimal protection of your industrial power supply
● 5-year warranty on your QUINT 4 power supply when installed together with PLT-SEC, see document in the download area
The powerful QUINT POWER power supplies with maximum functionality provide superior system availability thanks to SFB Technology
and individual configuration of signaling thresholds and characteristic curves. SFB Technology trips standard miniature circuit
breakers selectively. Loads connected in parallel continue working Preventive function monitoring reports critical operating
states before errors occur Power reserve for easy system expansion with static boost, providing sustained power of up to 125%.
Starting of difficult loads with a dynamic boost of up to 200% for 5 s High level of immunity with integrated gas discharge tube
and mains failure buffer time of more than 20 ms Robust design in metal housing and a wide temperature range from -40°C to +70°C
Power supplies with maximum functionality are part of the COMPLETE line system
For extreme operating conditions, use the ideally matched combination of PLUGTRAB SEC surge protection device and the powerful
QUINT POWER power supply of the fourth generation. However, should your fourth-generation QUINT POWER become damaged in the first
five years following purchase despite the use of this combination, you will receive a free replacement .
The Power Boost power reserve easily starts loads with high inrush currents and ensures that fuses are reliably tripped.
Preventive function monitoring diagnoses impermissible operating states and minimizes downtimes in your system. Remote monitoring
is provided by an active transistor switching output and a floating relay contact. All devices are idling-proof and
short-circuit-proof, and are available with a regulated and adjustable output voltage of 12, 24, and 48 V DC with output currents
of 2.5, 5, 10, 20, 30, and 40 A. Power supply units for use in Ex zone 2, uninterruptible solutions, AS-i power supply units, and
a QUINT diode complete this comprehensive product range.
Features:
● Startup of heavy loads, thanks to dynamic boost
● Preventive function monitoring reports critical operating states before errors occur
● High efficiency and long service life with low power dissipation and low heating
● Space savings in the control cabinet, thanks to a narrow, slim-line design
● Free selection between Push-in and screw connection
● QUINT POWER is the powerful 60 - 960 W DC power supply unit for universal use
With its wide-range input, single and three-phase versions, and international approval package, this solution is unrivalled
● QUINT POWER provides reliable power supply: generously dimensioned capacitors ensure mains buffering of over 20 ms at full load
● Full output power is provided by all three-phase devices, even in the event of a permanent phase failure
● Quick, tool-free installation with Push-in connection technology
● Increased service life and availability of the system, thanks to optimal protection of your industrial power supply
● 5-year warranty on your QUINT 4 power supply when installed together with PLT-SEC, see document in the download area
The powerful QUINT POWER power supplies with maximum functionality provide superior system availability thanks to SFB Technology
and individual configuration of signaling thresholds and characteristic curves. SFB Technology trips standard miniature circuit
breakers selectively. Loads connected in parallel continue working Preventive function monitoring reports critical operating
states before errors occur Power reserve for easy system expansion with static boost, providing sustained power of up to 125%.
Starting of difficult loads with a dynamic boost of up to 200% for 5 s High level of immunity with integrated gas discharge tube
and mains failure buffer time of more than 20 ms Robust design in metal housing and a wide temperature range from -40°C to +70°C
Power supplies with maximum functionality are part of the COMPLETE line system
