Shanghai Fangling brand Control system
with 7inch touchscreen, with built - in 48 figures,
you could choose pattern from these figures
directly, very convenient.
Plasma bảng CNC Plasma cắt bảng để bán 4x8 CNC Plasma bảng
999
Đã bán
82.485.464đ
74.871.421đ ~ 82.485.464đ
82.485.464đ
74.871.421đ ~ 82.485.464đ
Chọn loại hàng (ví dụ:màu sắc ,kích thước)
Thông số sản phẩm
0%
74.871.421đ
HZcf125Dbm
Mô tả sản phẩm
Kích thước: 1500*3000m mLoại động cơ: Động cơ bước
Điều kiện: MớiNơi xuất xứ: Shandong, China
Nhãn hiệu: JIAXINSố Mô Hình: JX-1530T
Điện áp: 220V/380VCông suất: 0.85 kg
Kích thước (L * W * H): 2000*3500*1500m mTrọng lượng (KG): 520 KG
Bảo hành: 1 nămKey Điểm Bán Hàng: Dễ dàng để Hoạt Động
Áp dụng Các Ngành Công Nghiệp: Vật Liệu xây dựng Cửa Hàng, Máy móc Cửa Hàng Sửa Chữa, Nhà Máy sản xuất, Xây dựng làm việc, Công Ty quảng cáoPhòng Trưng Bày Trí: Brasil, Peru, Ấn Độ, Nga, Thái Lan, Algérie
Tiếp Thị Loại: Sản Phẩm Mới 2020Máy Móc Báo Cáo Thử Nghiệm: Cung Cấp
Video Gọi Đi-Kiểm Tra: Cung CấpBảo Hành Của Core Thành Phần: 1 Năm
Core Thành Phần: Động Cơ, Hướng dẫn tuyến tính, đường sắt ngang, trạm nângSau bán hàng dịch vụ cung cấp: Kỹ sư có sẵn để phục vụ máy móc ở nước ngoài
Tên sản phẩm: Máy cắt plasmaMàu sắc: Tùy chỉnh
Độ dày cắt: 0.3-120mmTốc độ cắt: 0-8000mm/phút
Khu vực làm việc: 1500mm * 3000m mHệ thống cắt: Thương hiệu Shanghai fangling
Di chuyển chính xác: ± 0.2 mm/mPhần mềm: Fastcam hoặc stacam
Trọng lượng: 520kg
Product Description
1. Machine can cut any flat shape parts composed of straight lines and arcs.
2.The graphic is static and dynamic, easy to learn, can be programmed directly on the machine, or can be drawn on a computer or attached by using a ready-made CAD file. The gifted software is directly converted into a G code program file, and is automatically cut by copying it to the operating system through a USB flash drive.
3.Advantage: sigle-sided drive structure, exquisite system structure ,high degree of automation, simple operation, convenient maintenance, easy cutting from sheet metal to large thickness steel plate.
4.Application: machine can cut carbon steel, stainless steel, alloy steel, aluminum and other non-ferrous metal sheets.
Detailed Images
Shanghai Fangling brand Control system
with 7inch touchscreen, with built - in 48 figures,
you could choose pattern from these figures
directly, very convenient.
If metal sheets are rugged, should use
THC to adjust distance from torch to metal
surface.
Chinese best brand plasma power source
200A
Use soft switch inverter technology, to make cutting current very stable
Cutting current rise slowly, reduce consumption of cutting parts
Has a wide adaptability to grid voltage
Unique dust-proof design, high reliability
Compact structure, small volume, light weight, can be installed on many kinds CNC machines
use high precision linear guide, and light weight alloy-aluminum horizontal rail, not easy become deformation.
Cutting torch
Flame cutting torch is fixed, plasma cutting torch is mobile type.
Flame torch and plasma torch could be changed very easily.
Size Information
Technucal Parameters
1 | Model | JX-1530T |
2 | Power source | AC 220/380±10%VAC 50/60Hz |
3 | Cutting mode | O2/C3H8 or C2H2 |
4 | Effective cutting range(mm) | 1500*3000 |
5 | Input Voltage | 220V, 50HZ |
6 | Cutting speed(mm/min) | 0-6000mm/min |
7 | Cutting thickness(Flame) | |
8 | Cutting thickness(Plasma) | According to plasma power source |
9 | Move precision | ±0.2mm/m |
10 | Plasma THC | YES |
11 | Processing thickness(mm) | 0.3-32mm |
12 | Cutting system | Shanghai Fangling F2100T control system |
13 | Host weight(kg) | 520 |
14 | Gas pressure(Mpa) | Max.0.1 |
15 | Oxygen pressure(Mpa) | Max.0.7 |
16 | Type of gas | C3H8 C2H2 |
17 | Emergency stop | Yes |
18 | Working temperature | -5~45℃ |
19 | Plasma power | Chinese brand IGBT Plasma sources: Huayuan |
20 | ARC | Untouched arc striking |
21 | Processing Materials | Iron, stainless steel, carbon steel, copper sheets aluminum sheets, galvanized sheets, Titanium plates and other kinds metal |
Working pictures
JX-1212, JX-1530 table type CNC plasma cutting machine is used to cut 0.3- 32mm thin metal sheets, the metal sheet could be iron, stainless steel, aluminum, copper, Titanium, tin and many other kinds metal. Widely used in trucks, trailers, motorcycles, pressure vessls, general machinery, steel structure, ship and so on.
Related Products
Packing&Shipping
One machine picked in 2or3 wooden cases. Shipped by sea by LCL, or by truck, by air.
Company Introduction
Shandong Jiaxin Machinery Equipment Co.,Ltd.located in the hometown of Confucius and Mencius-Jining City, northwest of excellent transport location for communication between business and customers to provide a great convenience and fast.
Science and technology are primary productive forces"continuous advancement of technology is the development of the eternal source of power. The factory after nearly 20 years of development from a roller mold factory into a large-scale production of cold. Hot-rolled steel processing equipment. CNC steel processing equipment five series more than thirty kinds of products manufacturer enterprises.
We have always adhered to the "integrity of management, quality first&rdquo business philosophy customer for Gud's business objectives. Through a nationwide sales and service network, improve the pre-sale, selling service and after sale service sincere cooperation by providing quality products and efficient service for you.
Our Services & Strength
1.Pre-Sales Service:
1)Inquiry and consulting support.
2)We provide you the friendly English user manual and testing video free.
3)24 hours technical support by email or calling.
2.After-Sales Service:
1)Video of operating the machine are available.
2)12 months warranty quality guarantee and charge free technical support forever.
3)Free training to make sure you master the operating of machine.
FAQ
Q: What's the delivery time?
A: 10-15 working days to delivery port.
Q: What's the usually delivery terms?
A: FOB, CNF, CIF, Exworks will be OK.
Q: What's the MOQ?
A: 1 set.
Q: What&rsquos the payment term?
A: We accept T/T, L/C or Cash.
Q: What's your delivery port?
A: Usually Qingdao port, Shanghai port.
Q: What's the packing?
A: Iron Pallet and Plywood cases or carton or depending on your requires.
Q: Can I change the motor to my local voltage and frequency, Is thereany extra charge?
A: Yes, we can supply motor with frequency and voltage according to local standard. Such as 220V/380V/410V/415V/440V, and 50HZ/60HZ without extra charge.
Q: Can you place OEM orders?
A: Yes,OEM orders are acceptable. We can manufacture machines according to your requirement with your design,logo,color,materials or brand information.
Q:Where is your factory located? How can I visit there?
A:Our factory is located in Jining City, Shandong Province, China, about 2 hours from Beijing, 3 hours from Shanghai.
