Tốc Độ cao 12mm đến 40mm đường kính Thép Cây Cắt dòng CNC Dây Thép máy cắt Thanh 120KN
Tốc Độ cao 12mm đến 40mm đường kính Thép Cây Cắt dòng CNC Dây Thép máy cắt Thanh 120KN
Tốc Độ cao 12mm đến 40mm đường kính Thép Cây Cắt dòng CNC Dây Thép máy cắt Thanh 120KN
High Speed 12mm to 40mm diameter Rebar Shearing line Cnc Wire Steel Bar cutting machine 120KN
|
Model |
120kn |
HSL-1000 |
HSL-2000 |
HSL-3000 |
|||
|
Max. shearing power(kN) |
600 |
1000 |
2000 |
3000 |
|||
|
Width of blade(mm) |
150 |
250 |
450 |
600 |
|||
|
Frequency of cutting |
20 times/min |
||||||
|
Feeding speed of orbit(m/s) |
1.92 |
||||||
|
Cutting length of rebar(mm) |
500~12000 |
||||||
|
Working pressure(MPa) |
25 |
||||||
|
Rated power (kw) |
25 |
27 |
38.5 |
41 |
|||
|
Overall size(mm) |
27400x3250x1480 |
28000x6800x2600 |
28500x7100x2650 |
28100x7700x2850 |
|||
|
Weight(kg) |
6600 |
15500 |
17000 |
21000 |
|||
Cutting capacity (Grade III steel, 57kg/mm2)
(Note: The amount of shear reinforcement should be within the energy level)
|
|
&Phi12 |
&Phi16 |
&Phi20 |
&Phi25 |
&Phi28 |
&Phi32 |
&Phi40 |
&Phi50 |
|
120kn |
12 |
7 |
4 |
3 |
2 |
1 |
&mdash |
&mdash |
|
HSL-1000 |
20 |
12 |
7 |
5 |
4 |
3 |
1 |
&mdash |
|
HSL-2000 |
37 |
24 |
15 |
10 |
8 |
6 |
3 |
2 |
|
HSL-3000 |
50 |
37 |
23 |
15 |
12 |
9 |
5 |
3 |
we are manufacturer of pile cage welding machine , CNC automatic steel bar bending machine,bending machine ,cutting machine, steel bar straightening machine etc.we also can supply setting up a new factory full line service . We have already exported various kinds of concrete pile ,pole and pipe concern making machines to overseas countries and regions such as Indonesia, Parkistan, Vietnam, Myanmar ,Korea,Malaysia ,South african,Mideast Southeastern Asia, etc..
High Speed 12mm to 40mm diameter Rebar Shearing line Cnc Wire Steel Bar cutting machine 120KN
|
Model |
120kn |
HSL-1000 |
HSL-2000 |
HSL-3000 |
|||
|
Max. shearing power(kN) |
600 |
1000 |
2000 |
3000 |
|||
|
Width of blade(mm) |
150 |
250 |
450 |
600 |
|||
|
Frequency of cutting |
20 times/min |
||||||
|
Feeding speed of orbit(m/s) |
1.92 |
||||||
|
Cutting length of rebar(mm) |
500~12000 |
||||||
|
Working pressure(MPa) |
25 |
||||||
|
Rated power (kw) |
25 |
27 |
38.5 |
41 |
|||
|
Overall size(mm) |
27400x3250x1480 |
28000x6800x2600 |
28500x7100x2650 |
28100x7700x2850 |
|||
|
Weight(kg) |
6600 |
15500 |
17000 |
21000 |
|||
Cutting capacity (Grade III steel, 57kg/mm2)
(Note: The amount of shear reinforcement should be within the energy level)
|
|
&Phi12 |
&Phi16 |
&Phi20 |
&Phi25 |
&Phi28 |
&Phi32 |
&Phi40 |
&Phi50 |
|
120kn |
12 |
7 |
4 |
3 |
2 |
1 |
&mdash |
&mdash |
|
HSL-1000 |
20 |
12 |
7 |
5 |
4 |
3 |
1 |
&mdash |
|
HSL-2000 |
37 |
24 |
15 |
10 |
8 |
6 |
3 |
2 |
|
HSL-3000 |
50 |
37 |
23 |
15 |
12 |
9 |
5 |
3 |
we are manufacturer of pile cage welding machine , CNC automatic steel bar bending machine,bending machine ,cutting machine, steel bar straightening machine etc.we also can supply setting up a new factory full line service . We have already exported various kinds of concrete pile ,pole and pipe concern making machines to overseas countries and regions such as Indonesia, Parkistan, Vietnam, Myanmar ,Korea,Malaysia ,South african,Mideast Southeastern Asia, etc..
