ADS54RF63IPFP Giải pháp chip mạch tích hợp RF ADC hiệu suất cao của Texas Instruments dành cho truyền thông y tế công nghiệp
5
999
Đã bán
8.109.379đ
ADS54RF63IPFP Giải pháp chip mạch tích hợp RF ADC hiệu suất cao của Texas Instruments dành cho truyền thông y tế công nghiệp
Số lượng
Đơn vị
1 Đơn vị
Chọn loại hàng (ví dụ:màu sắc ,kích thước)
Thông số sản phẩm
Mô tả sản phẩm
Specification
Mounting Style:SMD/SMTPackage / Case:HTQFP-80Resolution:12 bitNumber of Channels:1 ChannelInterface Type:ParallelSampling Rate:550
MS/sInput Type:DifferentialArchitecture:PipelineAnalog Supply Voltage:4.75 V to 5.25 VDigital Supply Voltage:3 V to 3.6 VSNR -
Signal to Noise Ratio:62.6 dBMinimum Operating Temperature:- 40 CMaximum Operating Temperature:+ 85 CPackaging:TrayBrand:Texas
InstrumentsDevelopment Kit:ADS54RF63-ADX4DNL - Differential Nonlinearity:0.95 LSBENOB - Effective Number of Bits:9.9 BitFeatures:
High PerformanceHeight:1 mmINL - Integral Nonlinearity:4.5 LSBLength:12 mmMoisture Sensitive:YesNumber of Converters:1 Converter
Operating Supply Voltage:3.3 V, 5 VOutput Type:LVDSPd - Power Dissipation:2.5 WPower Consumption:2.25 WProduct:Analog to Digital
ConvertersProduct Type:ADCs - Analog to Digital ConvertersReference Type:External, InternalSFDR - Spurious Free Dynamic Range:76
dBSINAD - Signal to Noise and Distortion Ratio:61.3 dB96Subcategory:Data Converter ICsSupply Voltage - Max:3.3 V, 5 VSupply
Voltage - Min:3.3 V, 5 VWidth:12 mmUnit Weight:0.012984 oz
MS/sInput Type:DifferentialArchitecture:PipelineAnalog Supply Voltage:4.75 V to 5.25 VDigital Supply Voltage:3 V to 3.6 VSNR -
Signal to Noise Ratio:62.6 dBMinimum Operating Temperature:- 40 CMaximum Operating Temperature:+ 85 CPackaging:TrayBrand:Texas
InstrumentsDevelopment Kit:ADS54RF63-ADX4DNL - Differential Nonlinearity:0.95 LSBENOB - Effective Number of Bits:9.9 BitFeatures:
High PerformanceHeight:1 mmINL - Integral Nonlinearity:4.5 LSBLength:12 mmMoisture Sensitive:YesNumber of Converters:1 Converter
Operating Supply Voltage:3.3 V, 5 VOutput Type:LVDSPd - Power Dissipation:2.5 WPower Consumption:2.25 WProduct:Analog to Digital
ConvertersProduct Type:ADCs - Analog to Digital ConvertersReference Type:External, InternalSFDR - Spurious Free Dynamic Range:76
dBSINAD - Signal to Noise and Distortion Ratio:61.3 dB96Subcategory:Data Converter ICsSupply Voltage - Max:3.3 V, 5 VSupply
Voltage - Min:3.3 V, 5 VWidth:12 mmUnit Weight:0.012984 oz
Category | Integrated Circuits (ICs) Data Acquisition Analog to Digital Converters (ADC) | |
Manufacturer | Texas Instruments | |
Series | - | |
Packaging | Tray | |
Part Status | Active | |
Number of Bits | 12 | |
Sampling Rate (Per Second) | 550M | |
Number of Inputs | 1 | |
Input Type | Differential | |
Data Interface | Parallel | |
Configuration | S/H-ADC | |
Ratio - S/H:ADC | 1:1 | |
Number of A/D Converters | 1 | |
Architecture | Pipelined | |
Reference Type | Internal | |
Voltage - Supply, Analog | 3V ~ 3.6V, 5V | |
Voltage - Supply, Digital | 3V ~ 3.6V | |
Features | - | |
Operating Temperature | -40°C ~ 85°C | |
Package / Case | 80-TQFP Exposed Pad | |
Supplier Device Package | 80-HTQFP (12x12) | |
Mounting Type | Surface Mount | |
Base Product Number | ADS54RF63 |
